Product Drawing Material Materials

Product Drawing

Material

Base

UL94V-0 Thermoplaslic，black
Housing

UL94V-0 Thermoplaslic，black
Actuator

UL94V-0 Thermoplaslic，White
PIN

Phosphor Bronze,Gold plating

Materials

Rated current

-
Switching

25mA,24VDC
Non-Switching

100mA,50VDC
Initial

≤100mΩ
After Life Test

≤200mΩ
Dielectric strength

≥100mΩ/100VDC
Withstanding voltage

300VAC/1min
Operating Force

800g/Max
Mechanical Life

≥1000cycles
Operaqting Temperrature

-40℃～+85℃
Storage Temperature

-40℃～+85℃
