PCB Terminal Block KF136-10.16mm

PCB Terminal Block MATERIAL：Screws:steel,M4Tin platedblock：Brass, Tin platedTerminal:Brass, Tin platedHousing:PA66UL94V-0ELECTRICALRated voltage:600VRated current:50AContact resistance：20mΩDielectric strength:5000MΩ/1000VWithstanding voltage :AC3000V/1MinApplicable wire diameter:20～6AWG10mm2MechanicalService temperature:-40℃～＋105℃Max.soldering:+250℃for5SecTorque:1.2Nm(10.6lb.in)Strip length：10mm

Color
