PCB Terminal Block KF142V-5.08mm

Material：①Button：PA66，UL94V-0②Cover：PA66，UL94V-0③Button：PA66，UL94V-0④Reed：Stainless steel⑤Pin header：Brass，Tin platedElectricalULIECRated voltage300V 250V Rated current10A15AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range22-14AWG 1.5mm²MechanlicalTemp.rang-40℃～+105℃ Max.soldering+250℃,5sec

Color
