PCB Terminal Block KF141V-2.54mm

Material：①Button：PA66，UL94V-0②Cover：PA66，UL94V-0③Button：PA66，UL94V-0④Reed：Stainless steel⑤Pin header：Brass，Tin platedElectricalULIECRated voltage150V 130V Rated current5A6AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC1250V/1minWire range24-18AWG 1.0mm²MechanlicalTemp.rang-40℃～+105℃ Max.soldering+250℃,5sec

Color
