PCB Terminal Block KF390-5.00mm

Terminal Material：①Button：PA66，UL94V-0②Cover：PA66，UL94V-0③Reed：Stainless steel④Pin header：Brass，Tin platedElectricalULIECRated voltage300V 250V Rated current8A10AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range24-18AWG 1.0mm²MechanlicalTemp.rang-40℃～+105℃ Max.soldering+250℃,5secTorque-Strip length8

Color
