PCB Terminal Block KF260-3.50mm

Terminal Material：①Button：PA66，UL94V-0②Cover：PA66，UL94V-0③Button：PA66，UL94V-0④Reed：Stainless steel⑤Pin header：Brass，Tin platedElectricalULIECRated voltage300V 450V Rated current7A15AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range22-16AWG 1.5mm²MechanlicalTemp.rang-40℃～+105℃ Max.soldering+2

Color
