PCB Terminal Block KF188A-5.08mm

Terminal Material：①Button：PA66，UL94V-0②Cover：PA66，UL94V-0③Reed：Stainless steel④Pin header：Brass，Tin platedElectricalULIECRated voltage300V 450VRated current15A17AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC2000V/1minWire range24-14AWG 2.5mm²MechanlicalTemp.rang-40℃～+105℃ Max.soldering+250℃,5secTorque

Color
