PCB Terminal Block KF187A-2.54mm

Terminal Material：①Reed：Stainless steel②Housing：PA66,UL94V-0③Pin header：Brass，Tin platedElectricalULIECRated voltage150V Rated current4AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC1250V/1minWire range28-20AWG 0.5mm²MechanlicalTemp.rang-40℃～+105℃ Max.soldering+250℃, 5秒

Color

Line count

Consult more

Product Parameters

Product Drawing
