PCB Terminal Block KF120-2.54mm

Material：Screws:M1.5,Steel Zinc plated:Phosphor bronze,Ni platedorStainless steelPin header:Brass,Tin platedHousing:PA66,UL94V-0·ElectricalRated voltage:150VRated current:6AContact resistance:20mΩInsulation resistance:5000MΩ/1000VWithstanding voltage :AC1500V/1MinWire range:26-18AWG1.0mm²·MechanlicalTemp.rang:-40℃∽＋105℃Max.soldering:+250℃5/s Torque:0.15Nm(1.3ib.in)Strip length:3.

Color
