PCB Terminal Block KF635-6.35mm

PCB Terminal Block MATERIAL：Screws:M3.0steel,Ni platedContact material:BrassNi platedPin header:Brass, Tin platedHousing:PA66UL94V-0·ELECTRICALRated voltage:300VRated current:30AContact resistance:20m?Insulation resistance:5000m?\1000VWithstanding voltage :AC1500V\1MinWire range:26-10AWG4.0mm2·MechanicalTemp.rang:-40℃+105℃Max.soldering:+250℃5S torque:0.5Nm(4.5lb.in)Strip length:6-7mm
