Pluggable Terminal Block KF1025R-3.81mm

Pluggable Terminal Block MATERIAL：contact: -Pin header: Brass, Tin platedHousing: PA66，UL94V-0ElectricalULIECRated voltage300V 250V Rated current8A7AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC1500V/1minWire range-MechanicalTemp.rang-40℃～+105℃ Max.soldering+250℃, 5secTorque-Strip length- Make an appointment now

Color

Line count

Consult more

Product Parameters

Product Drawing
