Pluggable Terminal Block KF12EKR-3.81mm

Pluggable Terminal Block MATERIAL：M2.5，Steel Zinc platedClip:Phosphor bronze,Tin Platedcontact:Brass，Tin PlatedHousing:PA66，UL94V-0ElectricalULIECRated voltage300V250VRated current8A7AContact resistance20mΩInsulation resistance500MΩ/DC500VWithstanding voltage AC1500V/1minWire range26-28AWG0.5-1.5mm²MechanicalTemp.rang-40℃～+105℃Max.soldering+250℃,5secTorque0.2N.m2.4kgf.cmStrip length6-7mm

Color

Line count

Consult more

Product Parameters

Product Drawing
