Dip Switch KF1001-blue
Dip Switch Material:UL94V-0 Thermoplaslic,black Cover:UL94V-0 Thermoplaslic,Red blue black push button :UL94V-0 Thermoplaslic,White Terminal:Phosphor Bronze,Gold plating ElectricalElectrical life:2000 operations per switch 24VDC,25mARated current:10
Color
  • Kaifeng Electron
Line count
  • 01P
  • 02P
  • 03P
  • 04P
  • 05P
  • 06P
  • 07P
  • 08P
  • 09P
  • 10P
  • 11P
  • 12P
Product Drawing
Kaifeng Electron
Material
  • Base
    UL94V-0 Thermoplaslic,black
  • Cover
    UL94V-0 Thermoplaslic,Red Blue Black
  • Button
    UL94V-0 Thermoplaslic,White
  • Terminal
    Phosphor Bronze,Gold plating
Electrical
  • Electrical life
    2000 operations per switch 24VDC,25mA
  • Non-switching rating
    100mA,50VDC
  • Switching rating
    25mA,24VDC
  • Dielectric strength
    Minimum100MΩ,500VDC
  • Dielectric strength
    500VAC, 1 min
  • Capacitance
    Max5pF
  • The loop
    Single contact single selection
Mechanical
  • Operation Force
    10N(Max)
  • Stroke
    2.00mm
  • Operaqting Temperrature
    -40℃~+85℃
  • Storage Temperature
    -40℃~+85℃
Packaging
  • Net weight
    1.43 g
  • SPQ
    24pcs
  • Packing method
    Tube
  • MOQ
    1920pcs
  • Packing method
    箱装(525X290X240mm)
