PCB Terminal Block KF332-B-5.00mm

PCB Terminal Block MATERIAL：MATERIALScrews:M3.0Steel Zinc plated,"-"slot typeHousing:PA66,UL94V-0Reed:Phosphor bronze,Ni platedPin header:-ELECTRICALULIECRated voltage300V250VRated current10A24AContact resistance20mΩ(Max)Insulation resistance500MΩ\DC500VWithstanding voltage AC2000V\1MinWire range28-16AWG2.5mm²MechanicalTemp.rang-40℃～+105℃Max.soldering+250℃,5secTorque0.5N.m4.43L

Color
