PCB Terminal Block KF104-5.08mm
Material:①Screws : M3.0 Steel Zinc plated,"-"slot type ②Housing : PA66, UL94V-0 ③Square box :Brass,Ni plated ④Pin header : Brass, Tin plated &nb
Color
  • Kaifeng Electron
  • Kaifeng Electron
Line count
  • 02P
  • 03P
  • 04P
  • 05P
  • 06P
  • 07P
  • 08P
  • 09P
  • 10P
  • 11P
  • 12P
  • 13P
  • 14P
  • 15P
  • 16P
  • 17P
  • 18P
  • 19P
  • 20P
  • 21P
  • 22P
  • 23P
  • 24P
Product Drawing
Kaifeng Electron
Material
  • Screws
    M3.0 Steel Zinc plated-slot type
  • Housing
    PA66, UL94V- 0
  • Square box
    brass,nickel plating
  • Pin header
    Brass, Tin plated
Electrical
  • Rated voltage
    300V UL丨 250V lEC
  • Rated current
    10A UL丨 24A lEC
  • Contact resistance
    20mΩ(Max)
  • Insulation resistance
    500MΩ\DC500V
  • Withstanding voltage
    AC2000V\1Min
  • Wire range
    24-14AWG 2.5mm²
Mechanical
  • Temp Range
    LOW-40℃ 丨TOP+105℃
  • MAX Soldering
    +250℃,5sec
  • Torque
    0.4N.m 3.5Lb.in
  • Strip length
    6-7mm
Packaging
  • Net weight
    xg
  • SPQ
    12pcs
  • Packing method
    Bagged
  • MOQ
    12pcs
  • Packing method
    Boxed45cm*28cm*27cm
