PCB Terminal Block KF124D-3.81mm

PCB Terminal Block MATERIAL：Screws:M2.0Steel Zinc platedHousing:PA66,UL94V-0·ELECTRICALRated voltage:150VRated current:10AContact resistance:20mΩInsulation resistance:5000MΩ/1000VWithstanding voltage :AC1500V/1minWire range:26-16AWG1.5mm²·Mechanical(Mechanical)Temp.rang:-40℃～+105℃Max.soldering:+250℃,5 secondsStrip length:5-6mm

Color
